| Manufacturer | TE CONNECTIVITY |
|---|---|
| Product Category | Automotive Connectors |
| Product | Housing for Female Terminals |
| Number of Positions | 8 |
| Pitch | 9.12 mm [ .359 in ] |
| Mounting Style | Cable Mount (Free-Hanging) |
| Color | Black |
| Series | DT |
| Packaging | Box |
| Application | Wire-to-Wire |
| Contact Gender | Socket |
| Current Rating | 13 |
| Height | 37.21 mm [ 1.465 in ] |
| Housing Material | PA GF |
| Ingress Protection | IP68, IP6K9K |
| Length | 30.91 mm [ 1.217 in ] |
| Locking Mechanism | Integrated in Housing |
| Maximum Operating Temperature | 125 °C [ 257 °F ] |
| Minimum Operating Temperature | 125 C |
| Mounting Angle | 180° |
| Number of Rows | 2 |
| Product Type | Automotive Connectors |
| Subcategory | Automotive Connectors |
| Tradename | DT |
| Voltage Rating | 250 |
| Width | 19.71 mm [ .776 in ] |
Use the matching DT 8-pin male housing, plus its wedgelock and pin contacts, to complete the mating side.
Use the matching secondary lock with this DT 8-pin female housing.
Use female socket contacts with this DT 8-pin housing. Match the contact to the wire gauge. Do not use pin contacts on this side.
Use DT-RT1 for DT series contact removal. Use HDT-48-00 for closed barrel solid contacts.
