| Manufacturer | TE CONNECTIVITY |
|---|---|
| Product Category | Automotive Connectors |
| Product | Connector receptacle |
| Part Number | HDP26-18-6SN-C030 |
| Series | HDP20 |
| Compatible Series | HDP20 Series |
| Number of Positions | 2 Position |
| Gender | Female, Pin, Receptacle |
| Wire Gauge Range | 6 |
| Insulation | .280-.292 [7.11-7.42] |
| Color | Black |
| Contact Gender | Female, Pin, Receptacle |
| Contact Size | 4 |
| Current Rating | 100 |
| Housing Material | Plastic |
| Material | Plastic |
| Shape | Circular |
| Keyed | No |
| Shell Size | 18 |
| Seal Size | N seal |
| Cavities | 2 |
| Product Type | Automotive Connectors |
| Subcategory | Automotive Connectors |
| Tradename | HDP20 |
Use the matching DEUTSCH HDP20 2-position male pin housing side housing to complete the mating side.
Use the Deutsch contact release tool for the contact size shown. Use HDT-48-00 for Deutsch closed barrel solid contacts.
Use size 4 female socket contacts with this DEUTSCH HDP20 housing. Match contact size, wire gauge, and solid or stamped style before assembly.
Add the matching size 4 male pin contacts for the mating connector side.
Select the matching shell-size accessories such as backshells, boots, gaskets, dust caps, rings, and washers where required.
